- Place of Origin: China
- Brand Name: BLUE ELEPHANT
- Model Number: 1660
Number | Description | Parameter |
1 | X,Y,Z Working Area | 600x1600x200mm |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
4 | X,Y,Z Repositioning Accuracy | ±0.03mm |
5 | Table Surface | Vacuum & T-slot Table |
6 | Frame structure | Cast iron |
7 | X, Y Structure | 20#Taiwan HIWIN Linear guide and helical rack |
8 | Z Structure | Ball screw and#20 Taiwan HIWIN Linear guide |
9 | Vacuum pump | 7.5KW Vortex vacuum pump |
10 | Max. Rapid Travel Rate | 45000mm/min |
11 | Max. Working Speed | 30000mm/min |
12 | Spindle Power | 4.5KW Italy HSD air cooling spindle |
13 | Spindle Speed | 0-18000RPM |
14 | Drive Motors | Japan Panasonic |
15 | Inverter | 7 kw Taiwan Delta Inverter |
16 | Command Language | G Code |
17 | Control System | DSP |
18 | Computer Interface | USB |
19 | Flash Memory | 512M(U Disk) |
20 | Collet | ER32 |
21 | X,Y Resolution | <0.01mm |
22 | Software Compatibility | Type3 Software, (Option: Artcam Software) |
23 | Running Environment Temperature | 0 - 45 Centigrade |
24 | Relative Humidity | 30% - 75% |
