- Place of Origin: China
- Brand Name: BLUE ELEPHANT
- Model Number: 2030
Number | Description | Parameter |
1 | X,Y,Z Working Area | 2000x3000x900mm |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.01/300mm |
4 | X,Y,Z Repositioning Accuracy: | ±0.01mm |
5 | Table Surface | 20# Iron flat table |
6 | Frame | Divided structure ,Fixing with screws |
7 | Y Structure | Helical rack gear , 4pcs HIWIN inear guide |
8 | X,Z Structure | HIWIN #35 Linear guide |
9 | Max. Power Consumption | 12KW |
10 | Max. Rapid Travel Rate | 40000mm/min |
11 | Max. Working Speed | 30000mm/min |
12 | Spindle Power | 7.5kw |
13 | Spindle Speed | 0-18000RPM |
14 | Drive Motors | Japan 1.3KW YASKAWA servo |
15 | Working Voltage | AC380V/50/60Hz,3PH (Option: 220V)) |
16 | Command Language | G Code |
17 | Operating System | NK 105 |
18 | Computer Interface | USB |
19 | Flash Memory | 512M |
20 | Collet | ER32 (20mm) |
21 | X,Y Resolution | <0.01mm |
23 | Running Environment Temperature | 0 - 45 Centigrade |
24 | Relative Humidity | 30% - 75% |
